Nano Shield

Shield Arduino Nano

• Compatibility: Designed to fit directly onto the Arduino Nano board, providing easy plug-and-play functionality.
• Pinout Expansion: Offers additional pins for:
  • Digital Input/Output: Typically 14 pins for general-purpose digital interfacing.
  • PWM (Pulse Width Modulation) Outputs: Often includes 6 PWM pins for controlling motors, LEDs, and other devices that require analog-like control.
  • Analog Inputs: Provides 8 analog input pins for reading analog sensors and signals.
• Power Options: Usually includes power terminals or headers to connect external power sources or devices.
• Specific Functionality: Shields can be tailored for specific applications, such as motor control, sensor interfacing, wireless communication (e.g., WiFi or Bluetooth), or display modules (e.g., LCD or OLED).
• Stackable Design: Many shields are stackable, allowing multiple shields to be used together, expanding the Arduino Nano's capabilities further.

Applications:

• Prototyping: Ideal for rapid prototyping due to easy connectivity and expanded capabilities.
• Education: Used in educational settings to teach electronics, programming, and IoT concepts.
• Embedded Systems: Suitable for developing embedded systems and IoT devices requiring compact size and versatile functionality.
