LM 7474

The LM7474 is a Dual D-Type Positive Edge-Triggered Flip-Flop IC featuring preset and clear inputs for each flip-flop. It stores one bit of digital information and transfers the data present at the D (Data) input to the Q output on the positive-going edge of the clock signal. The asynchronous Preset (PRE) and Clear (CLR) inputs allow independent setting or resetting of the outputs regardless of the clock state

• Product Type: Dual D-Type Flip-Flop IC
• IC Number: LM7474
• Logic Family: TTL
• Number of Flip-Flops: 2
• Flip-Flop Type: Positive Edge-Triggered D-Type
• Package Type: DIP-14
• Operating Voltage (VCC): 4.75V to 5.25V
• Nominal Supply Voltage: 5V DC
• Logic Type: Dual D Flip-Flop with Preset and Clear
• Clock Trigger: Positive Edge
• Inputs: D, Clock (CLK), Preset (PRE), Clear (CLR)
• Outputs: Q and Q̅ (Complement)
