LM1117 -3.3 V

LM1117 -3.3 V

Voltage Regulator Specifications

• Maximum Input Voltage: 20V (VIN to GND)
• Output Voltage: 5V
• Line Regulation: 0.2% (maximum)
• Load Regulation: 0.4% (maximum)
• Package Type: TO-220
• Dimensions:
  • Length: 15.1mm
  • Width: 10.16mm
  • Height: 4.45mm
  • Approximate Weight: 4g
• Applications:
  • AC drive power stage modules
  • Merchant network and server PSU (Power Supply Units)
  • Industrial AC/DC applications
  • Ultrasound scanners
  • Servo drive control modules
