IC Base-18 PIN

IC socket with 18 pins

Header Connector

• Specifications:
  • Number of Positions: 18
  • Number of Rows: 2
  • Pitch: 2.54 mm (0.1 inches)
  • Distance Between Rows: 7.62 mm (0.3 inches)
  • Dimensions:
    • Width: 10.16 mm
    • Length: 17.78 mm
  • Termination Type: Solder Tail
  • Mounting Type: Open Frame

This header connector, with 18 pins arranged in two rows, is commonly used in electronic circuits for interfacing with other components or modules on a PCB.
