DRV8825 Stepper Motor Driver Module | High Current Stepper Driver Board for CNC, 3D Printer & Robotics
DRV8825 Stepper Motor Driver Module | High Current Stepper Driver Board for CNC, 3D Printer & Robotics
Description
The DRV8825 Stepper Motor Driver Module is a high-performance stepper motor controller designed for precise control of bipolar stepper motors. It is widely used in CNC machines, robotics, automation systems, and DIY motion control projects.
The module provides adjustable current control, microstepping support, and efficient motor operation using the DRV8825 driver IC. It allows smooth and accurate stepper motor movement with reduced vibration and improved positioning accuracy.
Compatible with popular controller boards such as Arduino, RAMPS, CNC controllers, and embedded systems, this compact driver module is suitable for engineers, makers, students, and robotics enthusiasts.
Specifications
- Product Type: DRV8825 Stepper Motor Driver Module
- Driver IC: DRV8825
- Motor Type Supported: Bipolar Stepper Motor
- Motor Supply Voltage: 8.2V to 45V DC
- Logic Voltage: 2.5V to 5.25V DC
- Output Current: Up to 2.2A per Coil (with proper cooling)
- Microstepping Modes: Full, 1/2, 1/4, 1/8, 1/16, 1/32 Step
- Control Interface: Step & Direction
- Current Adjustment: Adjustable Current Limit
- Protection Features: Over Current Protection, Thermal Shutdown, Under Voltage Lockout
- Cooling: Heat Sink Support
- Driver Type: Chopper-Based Stepper Motor Driver
- Compatible Platforms: Arduino, CNC Controllers, 3D Printer Boards, Embedded Systems
- Application: CNC Machines, 3D Printers, Robotics, Automation Projects
Applications
- 3D Printer Stepper Motor Control
- CNC Router Machines
- Laser Engraver Projects
- Robotic Arm Applications
- Arduino Motion Control Projects
- NEMA 17 Stepper Motor Control
- Automation Equipment
- DIY Mechanical Projects
