2.4 Inch TFT SPI LCD Display 240x320 Touch Screen Module with Touch Pen
2.4 Inch TFT SPI LCD Display 240x320 Touch Screen Module with Touch Pen
Couldn't load pickup availability
📦 For Bulk Order Enquiry – Click Here for Best Price
The 2.4 Inch TFT SPI LCD Display 240x320 Touch Screen Module with Pen is a compact full-color display module with a built-in resistive touch panel, designed for interactive electronics projects. It features a 240x320 pixel resolution TFT LCD with an SPI interface, allowing easy connection with microcontrollers and development boards.
This display module is suitable for Arduino, ESP32, ESP8266, STM32, and other embedded systems. The included touch pen enables accurate touch input for creating interactive menus, control panels, GUI interfaces, and smart device applications.
With vibrant color output and touch functionality, this module is ideal for robotics, IoT devices, automation systems, monitoring displays, and educational electronics projects.
Specifications
| Specification | Details |
|---|---|
| Product Type | TFT LCD Touch Display Module |
| Display Size | 2.4 Inch |
| Resolution | 240 × 320 Pixels |
| Display Type | Color TFT LCD |
| Interface | SPI |
| Touch Type | Resistive Touch Screen |
| Touch Pen | Included |
| Driver IC | ILI9341 (Typical) |
| Display Colors | 65K Colors |
| Operating Voltage | 3.3V / 5V Compatible (Module Dependent) |
| Communication | SPI Serial Interface |
| Backlight | LED |
| Screen Orientation | Portrait / Landscape Supported |
| Module Type | Touch LCD Display |
| Compatible Boards | Arduino, ESP32, ESP8266, STM32 |
Pin Configuration
| Pin | Function |
|---|---|
| VCC | Power Supply |
| GND | Ground |
| SCK / SCL | SPI Clock |
| MOSI / SDA | SPI Data Input |
| MISO | SPI Data Output |
| CS | Chip Select |
| DC / RS | Data Command Control |
| RESET | Display Reset |
| T_CS | Touch Chip Select |
| PEN / IRQ | Touch Interrupt |
Features
- 2.4-inch TFT color display
- 240x320 pixel high-resolution screen
- Built-in resistive touch panel
- Includes touch pen for accurate input
- SPI interface for simple wiring
- Supports graphics, images, and text display
- Compatible with popular TFT libraries
- Suitable for Arduino and ESP development boards
- Low power consumption
- Compact design for embedded applications
Applications
- Arduino Touch Screen Projects
- ESP32 GUI Projects
- IoT Control Panels
- Smart Home Displays
- Robotics Control Interface
- Industrial Monitoring Systems
- Data Logger Displays
- Digital Instruments
- Embedded User Interfaces
- Educational Electronics Projects
